Recommended Drive Rebuild Parts for Triple/S Dynamics Equipment
Replacement parts are available for all of your Triple/S Dynamics equipment. We provide replacement parts for all of our vibratory conveyor, density separation, and screening equipment lines. The typical sequence of inspected items once a drive is sent to our shop for inspection and/or rebuild: bearings, seals, sight glass, breather, belts, gears, weight stack hardware, visible oil/grease leaks, level in x and y, and inspection of the shafts.
See below for recommended preventative maintenance, partial rebuild, and full rebuild intervals.
Preventative Maintenance Recommended Every Year
To keep maintenance on track, start with a top-to-bottom audit of your Triple/S Dynamics equipment. Our recommended Category 1 preventative maintenance plan includes the following:
- Bearings
- Seals (Inner & Outer)
- Speedi Sleeves
- Shaft Retainers
- Support Washers
- Bolts (Bearing Housing)
- Nuts (Bearing Housing)
- Washers (Bearing Housing)
- Sight Gauge (Gear Case)
- Breather Assembly (Gear Case)
- Gasket (Gear Case)
- Loctite Sealant
- Loctite Retaining Compound
- Loctite Primer
Partial Rebuild Recommended Every 3-5 Years
The partial drive rebuild program can provide longer life without having to purchase a completely new unit. The partial rebuild includes everything from preventative maintenance, along with the following:
- Everything from Preventative Maintenance
- Shaft, Drive
- Shaft, Driven
- Seal Retainer, Inner (Gear Side)
- Seal Retainer, Inner (Drive Side)
Full Rebuild Recommended Every 5-10 Years
If your drives are 10, 15 or 20 years old, consider shipping the drive to our facility in Texas for inspection. We have a checklist/teardown list and will provide you with a detailed cost to rebuild your unit, which could save as much as 40% of the cost of a new drive. In the case that a full rebuild is required, everything from Preventative Maintenance & Partial Rebuild will be recommended, along with the following items:
- Everything from Preventative Maintenance & Partial Rebuild
- Gear Assembly Mode 3
- Bearing House (Gear Side)
- Bearing House (Drive Side)
